How to correctly understand Pneumatic Fitting?

Yueqing Jianghuai Pneumatic Technology Co., Ltd. has a relatively high reputation and market share in China. Its products are famous for their stable quality. Jianghuai takes pneumatic connectors as the starting point and has formed a comprehensive pneumatic product production line, making the Jianghuai brand recognized by many equipment manufacturers. Pneumatic Fitting, many people also call it quick connectors and quick plug connectors. Although the names are different, as long as you master the basic three points, you can judge the connector and select it.

1. Structural form

The so-called structural form is the appearance of the connector formed from the consideration of the pipe laying direction, diversion, and connection of Pneumatic Fitting. For example, T-type EPE, Y-type EPY, and straight-through EPC are all defined from the appearance structure.

2. Confirm the outer diameter or inner diameter of the trachea

On the basis of confirming the structural form, we need to confirm the outer diameter or inner diameter of the Pneumatic Fitting intubation. General quick connectors are for quick insertion of trachea, so it is necessary to confirm the outer diameter or inner diameter of the trachea.

3. Confirm the thread

For the joint with thread, it is necessary to confirm the thread specification. There are many thread specifications, the most common ones are R thread and G thread, and R thread is the most common.

After using Pneumatic Fitting, we need to cut and remove the burrs, insert one end of the air pipe into the socket of the metal pipe joint, and remember to press the joint ferrule with your thumb when removing the air pipe joint. You can pull out the air pipe with a little force. When using Pneumatic Fitting, we still have many details to pay attention to. We need to use it carefully to extend its service life and improve our production efficiency.
